Variable Power Supply Using Irfz44n MOSFET

                                           Variable Power Supply Using Irfz44n MOSFET

This Power Supply Is Regulate the voltage from 0.5 to 55 volt And up to 5 Amp Load You can control the resistive and inductive load But It can not control Resistive load because motor wants high Amp in Starting time And some Amp loss in regulating time so its not run the dc motor

Components Use To Making-

   -Irfz44n MOSFET

-10K Variable Resistor

-25v 1000 micro farad

-12-0-12 Transformer

-1k resistor

-Led For Indication

-SPST Switch

Circuit Diagram-
